➤830×800mm Extra-Large Engraving Area
➤48W High-Power Laser Output
➤ Auto-Focus & Ultra-Fine Spot Technology
➤ High Speed Up to 36000mm/min
➤ Z-Axis Offset Support
🚚 1–2 Day Dispatch | DHL / FedEx / UPS / USPS
Local warehouses in the U.S. and Europe
Quick response online chat system
Simply return it within 7 days for an exchange
We ensure secure payment with PEV
Create large-scale laser engraving projects with the powerful Sculpfun S40 MAX 48W laser engraver. Designed for workshops, makers, and small businesses, this machine features an extra-large 830×800mm working area that allows you to engrave or cut oversized materials such as wood panels, acrylic sheets, leather, and stone. Its rigid frame structure, advanced motion system, and ultra-fine laser spot ensure stable and precise engraving even at speeds up to 36,000 mm/min. With auto-focus, offline operation, and professional safety protection, the S40 MAX is an ideal solution for hobbyists, creative studios, and professional production environments.
The Sculpfun S40 MAX features a massive 830×800mm working area, making it ideal for large panels, signage, furniture parts, and batch production.
This expanded workspace significantly improves productivity and allows creators to handle projects that smaller engravers cannot accommodate.
Equipped with 12 high-efficiency 6W laser chips, the S40 MAX delivers up to 48W optical power.
This powerful laser enables one-pass cutting of 20mm plywood and 6mm dark acrylic, making it perfect for demanding cutting and engraving tasks.
With advanced fiber optic spot compression technology, the S40 MAX achieves an ultra-fine 0.154 × 0.121 mm laser spot.
Combined with Z-axis offset support in LightBurn, it enables smoother cutting edges, improved engraving detail, and reduced burn marks.
The built-in auto-focus function automatically adjusts the laser focus with a single button press.
Together with the cross positioning system and limit switches, it allows fast alignment and accurate positioning for efficient workflow.
The TS1 smart touch screen allows fully offline engraving without a computer. Users can also connect via Wi-Fi to the Sculpfun mobile app for convenient control.
Multiple safety features—including flame detection, tilt protection, emergency stop, and safety lock—ensure safe operation in workshops or studios.
| A. Laser Performance | |
|---|---|
| Model | Sculpfun S40 MAX |
| Laser Type | Diode Laser |
| Optical Output Power | 48W |
| Laser Wavelength | 455nm |
| Laser Module Lifetime | > 10,000 hours |
| Spot Size | 0.154*0.121mm |
| Beam Shape | Compressed rectangular spot |
| Power Stability | ±5% |
| Cooling Method | Air cooling |
| Focusing Method | Auto Focus + Manual Focus |
| Autofocus Support | Yes |
| Accessory compatibility | Sculpfun RA Pro Max, Sculpfun H4 Honeycomb, Sculpfun B70 Enclosure, Sculpfun SP1 Air Purifier |
| B. Working Capability | |
| Effective Working Area | 830 × 800 mm (32.7 × 31.5 in) |
| Expandable Working Area | No |
| Maximum Engraving Speed | 36,000 mm/min |
| Motion System Type | Industrial linear rail system |
| Upgradeable Laser Module | No |
| Cable Management Design | Integrated Cable Channels |
| Repositioning Precision | 0.1 mm |
| Z-axis Precision | 0.1 mm |
| Maximum Object Height | 50–80 mm (1.97–3.15 in) |
| Cutting Capacity | one-pass cutting of 20mm plywood and 6mm dark acrylic |
| Compatible Materials | Wood, plywood, MDF, acrylic, leather, fabric, cardboard, paper, rubber, bamboo, ceramic, slate, anodized aluminum, coated stainless steel, painted metal and other opaque materials |
| Ideal Applications | Custom product engraving, signage production, furniture decoration, prototyping, small-batch manufacturing, educational projects, maker workshops, Etsy business production |
| C. Control & Software | |
| Supported Software Platforms | LightBurn / LaserGRBL |
| Operating System Compatibility | Android / iOS / Windows / macOS |
| Connectivity Options | WiFi (via TS1) / USB |
| Supported File Formats | PNG, BMP, JPG, JPEG, DXF, PLT, AI, SVG, STL, OBJ |
| Firmware Type | 32-bit control firmware |
| Motherboard Type | 32-bit high-performance motherboard |
| D. Safety Features | |
| Laser Protection Cover | Sculpfun B70 Enclosure |
| Safety Interlock System | Yes |
| Flame Detection | Yes |
| Tilt Protection | Yes |
| Emergency Stop Button | Yes |
| Temperature Detection | No |
| Certification | CE / FCC / RoHS |
| E. Electrical Specifications | |
| Operating Voltage | DC 24V |
| Rated Current | 14.6A |
| Rated Input Power | 350W |
| F. Mechanical Structure | |
| Frame Material | High-strength metal |
| Machine Dimensions (W × D × H) | 1154 × 1113 × 240 mm (45.4 × 43.8 × 9.4 in) |
| Machine Weight | 15.2 kg (33.5 lbs) |
| Operating Temperature | 0–40 °C (32–104 °F) |
| G. Packaging & Logistics | |
| Package Dimensions | 1180 × 380 × 280 mm (46.5 × 15.0 × 11.0 in) |
| Gross Weight | 22 kg (48.5 lbs) |
| Packing List | S40 MAX Frame (5 pcs), 48W Laser Module, Laser Accessory Box, TS1 Touch Screen, Power Adapter, Power Cable, TS1 Adapter Cable, Data Cable, Air Pump, Fixed Focus Column, Screw Kit, Toolkit, Safety Goggles, User Manual |
