Acmer S1 Portable Mini Laser Engraving Machine

Name: Acmer S1 Portable Mini Laser Engraving Machine
Brand: ACMER
SKU: AcmerS1-2.5W-US
Price: 109.0 USD
Availability: InStock

$109.00

➤ Ultra-Portable & Lightweight Design
➤ High-Precision 0.04mm Laser Spot
➤ 130 × 130mm Optimized Engraving Area
➤ Fast Engraving Speed up to 10,000mm/min
➤ Wide Compatibility & Easy to Use

🚚 1–2 Day Dispatch | DHL / FedEx / UPS / USPS

FAST SHIPPING

Local warehouses in the U.S. and Europe

SUPPORT 24/7

Quick response online chat system

7 DAYS RETURN

Simply return it within 7 days for an exchange

PAYMENT SECURE

We ensure secure payment with PEV

ACMER S1 Portable Mini Laser Engraver – 0.04mm Precision, 130×130mm Work Area, 10,000mm/min, 2.5W / 3.5W / 6W

Whether personalizing gifts, producing custom ornaments, or running small-batch craft orders, the ACMER S1 delivers 0.04mm laser precision and 10,000mm/min engraving speed in a 1.5kg body that fits on any desk. Pre-assembled, factory-tested, and compatible with LightBurn and LaserGRBL out of the box, it works on wood, leather, acrylic, paper, and more. Built for DIY hobbyists, Etsy sellers, and classroom makers who need professional-grade results without a full workshop setup.

Ultra-Compact & Lightweight – Engrave Anywhere

Weighing just 1.5kg with a footprint of only 250 × 250 × 162mm, the ACMER S1 is one of the most portable diode laser engravers available — small enough to travel with, sturdy enough to handle daily production.

Unlike bulkier machines that demand a dedicated workbench, the S1 sits comfortably on a desk, shelf, or studio cart. It ships fully pre-assembled and factory-tested, so beginners and professionals can unbox and start engraving in minutes without complex setup or calibration.

0.04mm Laser Spot & 0.01mm Engraving Accuracy

The S1's ultra-fine 0.04 × 0.04mm compressed laser spot reproduces intricate artwork, fine text, detailed portraits, and complex vector patterns with exceptional sharpness — detail that lower-precision engravers simply cannot match at this price point.

With a motion accuracy of 0.01mm and a laser module rated for over 10,000 hours of operation, the S1 maintains consistent quality across long sessions and repeated batch jobs. Available in 2.5W, 3.5W, and 6W to match your specific material and output requirements.

Optimized 130×130mm Work Area with Frame Scale

The S1's 130 × 130mm (5.1 × 5.1 inch) engraving area maximizes the usable space within its compact frame — well-suited for keychains, coasters, phone cases, ceramic tiles, ornaments, and small signage pieces.

Precision X- and Y-axis scale markings are machined directly into the frame, enabling accurate material alignment and repeatable placement without external rulers or jigs. Combined with dual-axis limit switches for automatic origin return, the S1 resets position reliably between jobs — essential for consistent batch production.

10,000mm/min Speed Across Wood, Leather, Acrylic & More

The ACMER S1 supports engraving speeds up to 10,000mm/min, enabling efficient throughput without sacrificing the edge quality or line consistency that precision projects demand.

It engraves and marks a wide range of materials including wood, plywood, MDF, leather, paper, cardboard, fabric, bamboo, plastic, acrylic, rubber, anodized aluminum, painted metals, coated stainless steel, ceramics, slate, and dark glass — covering the full range of DIY craft projects, personalized gifts, and small-business production runs.

LightBurn & LaserGRBL Compatible – Windows & macOS

The ACMER S1 works natively with LightBurn and LaserGRBL — the two most widely used laser engraving software platforms — on both Windows and macOS, with no proprietary drivers or locked ecosystems.

It supports a broad range of file formats including JPG, PNG, BMP, SVG, AI, GIF, G-code, CAD, CDR, DWG, and more. The 450nm ± 5nm diode laser wavelength is optimized for contrast-rich engraving across both organic and coated materials — ensuring predictable, repeatable output across your entire workflow.

Specifications

A. Laser Performance
Model	ACMER S1
Laser Type	Diode Laser
Laser Output Power	2500mW / 3500mW / 6000mW
Laser Wavelength	450 ± 5nm
Laser Spot Size	0.04 × 0.04mm
Engraving Accuracy	0.01mm
Focal Length	2mm
Laser Module Life	>10,000 Hours
B. Working Capability
Working Area	130 × 130mm (5.1 × 5.1 in)
Maximum Engraving Speed	10,000 mm/min
Machine Power	24W / 36W / 48W
Frame Scale	Integrated X- and Y-axis scale markings
Limit Switches	Dual-axis (X + Y) for auto origin return
Compatible Materials	Wood, plywood, MDF, leather, paper, cardboard, fabric, bamboo, plastic, acrylic, rubber, anodized aluminum, painted metal, coated stainless steel, ceramics, slate, dark glass, cork, felt
Ideal Applications	Personalized gifts, keychains, coasters, ceramic tiles, small signage, ornaments, jewelry tags, leather goods, DIY projects, Etsy small-batch production
C. Control & Software
Control Software	LightBurn / LaserGRBL
Operating System	Windows / macOS
Connectivity	App
Supported File Formats	JPG, PNG, BMP, GIF, SVG, AI, G-code, CAD, CDR, DWG, and more
D. Electrical Specifications
Power Supply	DC 12V / 2A (2.5W) · DC 12V / 3A (3.5W) · DC 12V / 4A (6W)
Machine Power	24W / 36W / 48W
E. Mechanical Structure
Machine Body Size	250 × 250 × 162mm
Machine Weight	1.5kg
Assembly	Pre-assembled, ready to use out of the box
